Features

◦   Light source: long life pulsed xenon flash lamp

◦   Detector: 2048-element linear silicide CCD array

◦   Wavelength range: 190 ~ 850 nm

◦   Wavelength accuracy: ± 1 nm

◦   Wavelength resolution: 2 nm (FWHM at Hg 546 nm)

◦   Repeatability: <± 0.5 nm

◦   Light path: 1 mm, 0.05 mm (optical path automatic conversion)

◦   Nucleic Acid measurement range: 0.4 ~ 37500 ng/μl (DS-DNA)

◦   Protein measurement range: 0.01 ~ 800 mg/ml (BSA)

◦   Sample volume: 0.5 ~ 2 μL

◦   Absorbance Accuracy: 1% (0.76 absorbance at 350 nm)

◦   Absorbance range: 0.002 - 750 (equivalent to 10 mm path length)

◦   Cuvette mixing system: mixing system available,

◦   so that the sample concentration is more uniform

◦   Sample measurement time: less than 5 seconds

◦   Sample base material: stainless steel and quartz fiber

◦   Cuvette specifications (optical path): 1 mm, 2 mm, 5 mm, 10 mm

◦   Minimum sample volume of the cuvette: 20 μl

◦   The minimum height of the cuvette sample: 5 mm

◦   Cuvette Type: A cuvette with a traceable cuvette specification

◦   Cuvette Anechoic Chamber:

     A standard cuvette darkroom with a wide variety of cuvettes

Functions

10 ~ 42 ˚C adjustable thermostat with error <± 0.5 ˚C

USB port or network to communicate

No need for preheating, boot and test;

Liquid column to determine abnormal function

Simple operation process with automatic test function

Built-in wifi, remote operation can be achieved

Test result can be printed wirelessly

Built-in detection system, high-definition display, touch screen
